Swage Nipple Threaded Pipe Fittings

Swage Nipple and short joint reducing joint are pipe fittings used for straight-line connection of two pipes with different sizes to realize pipe diameter reduction. There are concentric reducing joint and eccentric reducing joint

Threaded Pipe Fittings Swage Nipple Manufacturer

Pipe Fittings Swage Nipple

Content

Swaging nipple (also known as reducing nipple) is a forged pipe fitting. It is used to change the diameter of the pipe and connect two pipes of different sizes.

Shapes:

Concentric: Concentric swage nipple is mainly used for vertical pipeline.

Eccentric: eccentric swage nipple is mainly used in horizontal pipelines.

End Types:

PBE=Plain Both Ends

PLE=Plain Large End

PSE=Plain Small End

POE=Plain One End

TOE=Thread One End

TBE=Thread Both Ends

TLE=Thread Large End

TSE=Thread Small End

BBE=Bevel Both Ends

BLE=Bevel Large End

Shape	Elbow,Tee, Cross, Coupling, Cap, Swage Nipple, Bushing, Plug, Nipple, Union, Hex Nipple,Threadolet.
Size Range	1/8″ – 4″ / DN6 – DN100
Pressure Rating	Class 2000lbs, 3000lbs, 6000lbs
Thread Type	NPT, PT, BSPP, BSPT, PF
Standard	ASME B16.11, BS3799, EN 10241, MSS SP-83, MSS SP-97
Carbon Steel	ASTM A105 / A105N, ASTM A350 LF2/LF3, ASTM A694 F42 / 46 / 56 / 60 / 65, P235GH, P265GH, P280GH, P355GH
Alloy Steel	ASTM A182 F11 / 12 / 5 / 9 / 91 / 92 / 22
Stainless Steel	ASTM A182 F304/304L/304H, 316/316L, 321, 310S, 317, 347, 904L，1.4404, 1.4437.
Duplex Stainless Steel	ASTM A182 F51, F53, F44

Applications
- Water supply facilities
- Food industrial pipelines
- Chemical industrial pipelines
- Electronic industrial pipelines
- Air conditioning facility pipelines
- Agriculture and garden production transportation
- Pipeline network for solar energy facility
