Hex Bushing Reducer Pipe Fitting 1/8 1/4 3/8 1/2 3/4in toThreaded Reducer

Weldolet, an economical butt-weld branch connection, is designed to minimize stress concentrations and provide integral reinforcement. manufactured to meet your specific reinforcement requirements.

High pressure tee is used for adding pipe branchs. An equal tee, otherwise called straight tee, means the branch diameter of this tee is same with the main pipe (Run pipe) diameter of this tee.

Threadolet considered to a threaded fitting, and it is manufactured in 3000 and 6000 classes.

 NPT A105 bushing is mainly used to connect two pipes of different diameters in the pipeline system or to correct the error in the pipeline installation. It is usually made of A105 carbon steel, has high strength and good corrosion resistance, and can withstand high working pressure.

Carbon Steel A105 Threaded Tee are commonly used carbon steel grade which is used to manufacture forge piping components such as forged fittings and flange of small diameter piping, generally for piping whose nominal diameter is NPS 2 or smaller.

Swage Nipple and short joint reducing joint are pipe fittings used for straight-line connection of two pipes with different sizes to realize pipe diameter reduction. There are concentric reducing joint and eccentric reducing joint

According to its radius of curvature, there are long radius elbow and short radius elbow. Long radius elbow refers to its radius of curvature is equal to 1.5 times the outside diameter of the pipe, that is, R=1.5D; A short radius elbow means that its radius of curvature is equal to the outer diameter of the pipe, that is, R= 1.0d.(D is the diameter of the elbow, and R is the radius of curvature).

What is a plug,what about its specification and its difference between a caps.

ASTM A182 F304L forged fittings are high pressure pipe fittings which can used in many industries because of the excellent functions.DN25 threaded pipe tees are small size fittings but an indispensable part in piping systems.

SS304 90 deg elbow is a stainless steel pipe fitting used to changes the direction of the flow in 90 degree.Threaded steel pipe fittings are a type of forged steel pipe fittings.The other forged fitting is SW pipe fitting.

hat is a threaded tee,what about its specification and its difference between a elbow.

Swaging nipple (also known as reducing nipple) is a forged pipe fitting. It is used to change the diameter of the pipe and connect two pipes of different sizes.

Type: Full and Half Coupling
Shape: Straight and Reducing Coupling
Thread Type: NPT, PT, BSPP, BSPT, PF
Size Range: 1/8″ –  4″ / DN6 – DN100

ASTM A182 F316 pipe nipples have two shapes:TOE (threaded one end) and TBE (threaded both ends).The nipples in the picture are all in TOE shape.The pressures can be chosen:CL2000,CL3000,CL6000.

Steel tee is a T-shaped pipe fitting with three branch pipes. It is used to divide pipes to adjust flow and change direction.

What is a threaded tee,what about its specification and its difference between a elbow.

Threaded Pipe Fittings Specification
Shape: Elbow,Tee, Cross, Coupling, Cap, Swage Nipple, Bushing, Plug, Nipple, Union, Hex Nipple,Threadolet.
Size Range: 1/8″ –  4″ / DN6 – DN100
Pressure Range: Class 2000lbs, 3000lbs, 6000lbs
Thread Type: NPT, PT, BSPP, BSPT, PF
Standard: ASME B16.11, BS3799, EN 10241, MSS SP-83, MSS SP-97

Stainless steel threaded pipe fittings are very popular forged fitttings because of the excellent anti-corrosion function.ASME B16.11 forged pipe fittings are SW pipe fittings and THD fittings.There are threaded pipe fittings in the picture.SHANGHAI ZHUCHENG PIPE FITTINGS MANUFACTURING CO LTD is an excellent pipe fittings and flanges supplier from China.

Swage Nipple are similar to reducers, but they’re smaller, and they’re used to link larger screwed, or socket welded pipes to smaller screwed or socket welded pipes. They come in concentric and eccentric varieties, just like reducers. Swages come in a variety of end

Shapes:
Equal：This is a Pipe fitting with the same size on three sides.
Reducing：The main pipe of these tee is different from the diameter of the branch pipe, and the diameter of the main pipe is larger than that of the branch pipe.

The weld groove of the branch abutment is a single-sided V-shaped groove. It can be determined that the weld is a combination of butt weld (groove weld) and fillet weld.

What is aHex Nipple and what about its specification and advantages.

ASTM A182 F316 is a popular grade for stainless steel in American Standard.Stainless steel fittings are popular because of the an-ti corrosive function.Stainless steel pipe fittings can used over 50 years.

Equal tees are available in sizes from half an inch to 48 inches (or larger) and in seamless and welded execution (seamless up to 24 inches, welded for tee sizes above 24 inches).

Swaging nipple (also known as reducing nipple) is a forged pipe fitting. It is used to change the diameter of the pipe and connect two pipes of different sizes.

Class 3000 threaded union is the most used pressure of threaded union.ASME B16.11 is the standard for forged fittings according to American Standard.
