Black steel A234 WPB Pipe fitting accessories Images

BW cap is used to close the pipe system,the function is similar to plug.A234 WPB is a commonly used grade for carbon steel in American Standard.SCH 40S is represents a wall thickness of butt welded fittings.The commonly used wall thicknesses for BW fittings are SCH 40,SCH 80.

BW equal tee is a commonly used tee in many applications.There is also reducing tees to choose.These tees have same functions,the only difference is the reducing tees can reduce the flow in the pipe system.There are the tee specifications in content below.

The two ends of concentric reducer are designed with large diameter and small diameter, and the pipe is connected through conical transition section on the same axis.

90 deg elbow is the most used degree in elbows,.Butt welded fittings including BW elbows which used welded connection to connect with pipes.There is also 45 degree elbows.These elbows have similar functions,the only difference is the 90 degree elbow can changes the direction in 90 deg while the 45 degree elbow can changes in 45deg.

It helps to change direction at 90 degree, and is commonly used to connect hoses to pumps, deck drains and valve.SR 90 degree elbow is the same as the pipe elbow mentioned above, but the diameter is shorter. Therefore, this kind of steel elbow is often used when space is not enough.A 90 degree elbow attaches readily to plastic, copper, cast iron, steel and lead. It can also attach to rubber with stainless steel clamps. Available in many materials like silicon, rubber compounds, galvanized steel etc.

Equal butt weld elbow is used to change the direction of the flow in piping system.SCH 80 is a commonly used wall thickness for butt welded fittings,the other commonly used wall thickness is SCH 40.

BW elbows have the most wide used range in all types of elbows.Shanghai Zhucheng is an excellent supplier for pipe fittings,all the fittings made from carbon steel and alloy steel will have anti-rust paint,and stainless steel fittings will have anti-rust oil to protect the fittings in the sea transportation.

BW (butt welded) reducer can be concentric (COC) reducer and eccentric (EEC) reducer.Among these two types,concentric reducer is more commonly used.The materical of reducer can be carbon steel,alloy steel and stainless steel.Clients can choose different material as their demands.

ASME B16.9 butt welded fittings are American Standard BW fittings.COC Reducer means concentric reducer,BW reducers can be concentric (COC) reducer and eccentric (ECC) reducer.These reducers have same functions,the only difference is the internal structure.

This kind of elbow is classified by angle, and 45 degree elbow and 180 elbow is also very popular. And steel pipe elbow is also available in 60 degree, 30 degree and other special angle according to practical needs.

Carbon steel butt weld reducer is belong to ASME B16.9 pipe fittings,there are concentric reducer and eccentric reducer for chosen to meet different demands.

ASME B16.9 45 degree LR elbow is a pipe connector with a bending angle of 45 degrees. The long diameter means that the bending radius of the elbow is relatively large. It consists of a bending part and interfaces at both ends. The size of the interface matches the outer diameter of the connected pipe to ensure a sealed connection.

Compared to 90 degree elbow, 45 degree elbow produces less friction, and with the lower pressure. 45 degree elbow is widely used in chemical industry, food, water supply facilities, electronic industry, chemical pipeline, horticulture, agricultural production, solar equipment pipeline, air conditioning pipeline and other fields.

Steel pipe elbows have seamless and welded version, normally in 90 degree, 45 degree & 180 degree. Material are carbon steel, alloy steel & stainless steel. BW 90 degree elbow is formed by hot forming and connects steel pipes or other pipe fittings through butt welding process

Steel pipe tee is a pipe fitting used to tansport the flow in the piping system.Carbon steel fittings are used in many applications becasue of its great excellent functions.

What is a latera tee and the difference between a wye and a lateral?

Stainless steel pipe fittings including Tee,Cross, Elbow, Reducer, Coupling, Nipple, Plug & Cap,Union.They can be connected with pipes by welding, socket and thread.

BW tees and reducers are the most used pipe fittings in the piping system.Tees can branch the flow in piping systems.Carbon steel pipe fittings are popular as the great functions and affordable functions.

90 deg 4D bend is belongs to butt welded fittings.4D means the radius of the bend is 4 times long the dimension of the pipe bend.API A53B is a great of carbon steel materical for pipes and bends in American Standard.

Pipe tees can be two types:Reducing Tee and Equal Tee.Both types of tees can branch the pipes in the piping systems.Schedule 40 is a wall thickness of the butt welded fittings,the commonly used schedules are SCH 40,SCH 80.

BW carbon tee are popular because carbon steel has great functions and cheap price.Coated pipe fittings also used in piping systems as the coating can enhance the functions for normal carbon steel.Galvanized coating is the most used coating,it can enhance the anti-resistance function.

Butt welded lateral tee is a special type of BW tees.It is different from the normal tees as the lateral tee can change the direction of the pipe system in 45 degree.Carbon steel fittings are the most used fittings as carbon steel material has great functions and affordable price.

A234 WPB/WPC BW concentric reducers are carbon steel butt welded fittings,among these,A234 WPB is more chosen in many industries.BW reducers can be concentric (COC) reducer and eccentric (ECC) reducer.These reducers have same functions,the only difference is the internal structure.

45 deg elbow can change the direction of fluids or gas in 45 degree.There is also has 90 deg elbow to be chosen.45 degree elbow has many diffences with 90 degree elbow.All types of elbows can be Equal Tee and Reducing Tee to satisfy different demands.

Carbon steel elbows are the most commonly used elbows in all the types and material elbows.Large dimensions elbow is butt welded fitting,you can find the butt welded fittings specification below.

Elbows are split into two groups which define the distance over which the flowing fluid change direction; the center line of one end to the opposite face. This is known as the “Center to Face” distance and is equivalent to the radius through which the elbow is bent.

Long radius elbow refers to the pipe outer diameter with radius of curvature equal to 1.5 times, i.e R = 1.5D. Most elbows are available in short radius or long radius variants. When the two ends differ in size, the fitting is called a reducing elbow or reducer elbow.

There are two types of 90 deg elbows:LR (long radius),SR (short radius).45 deg eblows are also have wide applications,be attention,45 deg elbow only have LR type.Butt welded pipe fittings have the most large used range as it can be 1/2″ – 80″.
