ASTM A105N Carbon Steel Socket Weld Union MSS SP-83

SPECIFICATION Of Socket Weld Elbows and its advantages.

What is a SOCKET WELD-90 DEGREE ELBOW,what about its speicification and advantage

Socket weld elbow is a forged fitting belongs to SW fittings,SW fittings can be socketed with pipes and then welded with the pipes.SW fittings have serive of pressures:Class 3000,Class 6000,Class 9000.Among these,the most used pressure is Class 3000.

ASTM A182 F316 is a popular grade for stainless steel in American Standard.Stainless steel fittings are popular because of the an-ti corrosive function.Stainless steel pipe fittings can used over 50 years.

Carbon steel pipe fittings are used in many applications because of its great excellent functions.Carbon steel pipe fittings can manufactured as THD (threaded) fittings,SW (socket weld) fittings and (BW) butt welded fittings.The specifications are in the content below.

Socket Weld half Coupling is a coupling with a socket weld only at one end, It is usually welded directly to the pipeline to form a branch connection. Coupling for joining a pipe to another of smaller diameter. Straight coupling connects two pipes end-to-end. It is used to supplement the infinite aluminum pipe.

What is a socket weld elbow and why do socket welders need a gap?

Flush Bushing: Flush bushing are used in piping systems. They are installed in the pipe to reduce the size of the pipe. Forged bushing is ideal for use with water and oil in chemical, petrochemical, pulp, paper, shipbuilding, waste incineration, and semiconductor industry applications.

Socket Weld Tee Material: ASTM A105 / A105N, ASTM A350 LF2/LF3, ASTM A694 F42 / 46 / 56 / 60 / 65, P235GH, P265GH, P280GH, P355GH

An equal tee, otherwise called straight tee, means the branch diameter of this tee is same with the main pipe (Run pipe) diameter of this tee.
A pipe tee is defined “equal” when the bore size at the run and branch sides have the same diameter. An equal tee is, therefore, used to connect two pipes of the same nominal diameter.

SW tee can socketed with the pipes and welding with the pipes.ASME B16.11 fittings are forged fittings according to American Standard.Tees can be equal tee and reducing tee.These tees have same functions,the only difference is reducing tee can reduce the flow in piping system.

90 deg socket weld elbows are belong to ASME B16.11 stainless steel pipe fittings.SW elbows have two types:90 DEG and 45 DEG.SW pipe fittings including:Elbow, Tee, Cross, Coupling, Union, Cap, Reducing Insert, Sockolet.Three pressures for customers to choose:3000LB,6000LB,9000LB.

SW (socket weld) elbow is high pressure forged fitting which can used in many industries ‘ pipe systems.SW elbows have 90 deg and 45 deg.SW elbows have pressures: 3000LB,6000LB,9000LB.SS304 fittings are always used in chemical industries because of the excellent corrosion resistance.

Socket weld pipe fittings is a family member of forged steel fittings, which used for small bore pipes and piping systems (generally below 4 inches). We usually manufacture them according to ASME B16.11 standard.

Stainless steel pipe fittings including Tee,Cross, Elbow, Reducer, Coupling, Nipple, Plug & Cap,Union.They can be connected with pipes by welding, socket and thread.

SW elbow is used to socket with the end of pipe and welding on it.Socket weld elbow is belong to forged fittings which are used as high pressure fittings,SW fittings can be 2000lb,3000lb,6000lb.

Coupling is a connector used to screw two pieces of pipe together using threaded rings, It is used for fittings that connect two pipes more closely in a piping system. .Socket Weld half Coupling is a coupling with a socket weld only at one end, It is usually welded directly to the pipeline to form a branch connection.

ASME B16.11 is the standard contains ratings, dimensions, tolerances, marking and material requirements for forged fittings, both socket-welding and threaded. Threaded fittings are available in pressure ratings Class 2000, 3000, and 6000; Socket welding fittings are available in pressure ratings Class 3000, 6000, and 9000.

There are various grade for Stainless Steel Forged Pipe Fittings: ASTM A182 F304/304L/304H, 316/316L, 321, 310S, 317, 347, 904L，1.4404, 1.4437.

Socket weld Elbow forged fitting has varieties of features such as reliability, durability and dimensional precision.

What is a Socket weld Uninon,what about its speicification and advantage

There are various types of ASME B16.11 socket-welding fittings, such as Elbow, Cross, Tee, Socked Weld Coupling , Half Coupling, Boss, Cap, Union and Sockolet.
